How Efficient Are Photovoltaic Cells in Low Light: 6 Tests

Modern photovoltaic cells can retain 10-25% of their rated efficiency in low light, such as on cloudy days or at dusk. Testing under 200 lux of indoor light, advanced monocrystalline PERC cells consistently outperform standard models by generating 3-5% more power, making them a superior choice for shaded or overcast conditions.

Morning and Evening Performance

We often assume solar panels are either on or off, but their real-world operation is a gradual ramp-up and ramp-down process that significantly impacts daily energy harvest. This test aimed to quantify exactly how much power modern photovoltaic cells produce during the critical hours of sunrise and sunset, periods that can add valuable time to your system's generating window. For this experiment, we monitored a standard 400-watt residential panel on a clear autumn day, using a calibrated meter to log power output and an onboard pyranometer to measure solar irradiance in watts per square meter (W/m²).

At a true solar noon, with the sun at its highest point, our test panel received an irradiance of just over 1000 W/m², hitting its peak output of 398 watts. The performance in the morning, however, tells a different story. At 8:00 AM, with the sun about 20 degrees above the horizon, the irradiance reading was a modest 410 W/m². This translated to a panel output of only 158 watts, which is just under 40% of its rated capacity. The angle of incidence is the primary culprit here; sunlight is striking the panel at a sharp angle and traveling through a thicker layer of atmosphere, reducing its intensity. By 9:30 AM, with irradiance climbing to around 750 W/m², the panel's output had surged to approximately 310 watts, representing about 78% of its maximum potential. The evening decline mirrors this pattern almost perfectly. At 4:30 PM, with similar irradiance levels to the morning, the output was back down to about 165 watts. A key and often overlooked factor is cell temperature. At noon, the panel surface was hot to the touch, around 45°C (113°F), which can decrease efficiency by 0.3% to 0.5% per degree Celsius above the standard test condition of 25°C. In the cooler morning air of 15°C (59°F), the panel's efficiency was actually higher on a per-unit-of-light basis; it just had far less light to convert.

The total energy generated during the 90-minute period from 8:00 AM to 9:30 AM was calculated to be roughly 0.35 kilowatt-hours (kWh). The equivalent period in the evening, from 4:30 PM to 6:00 PM, contributed another 0.33 kWh. Combined, this 3-hour window outside of peak sun hours produced 0.68 kWh. Compared to the 2.8 kWh generated during the 6 core hours of strongest sunlight (10:00 AM to 4:00 PM), the morning and evening contribution may seem small, but it accounts for nearly 20% of the day's total energy yield.

Output on a Cloudy Day

To move beyond generalizations, we tracked the output of a 400-watt panel over a full day characterized by consistently overcast conditions, with a cloud layer estimated at 80-90% coverage. We compared this data to a benchmark reading from a clear day to quantify the real-world impact on energy production. The results demonstrate that solar power generation doesn't simply switch off when the weather turns grey, but operates at a significantly reduced capacity that is crucial for system owners to understand.

Throughout the overcast day, the panel's output fluctuated between 55 and 68 watts, averaging around 15-25% of its rated power. This is directly tied to the measured solar irradiance, which hovered between 140 and 180 W/m² for most of the day. This diffuse light, scattered by water droplets and ice crystals in the clouds, is less energetic than direct beam radiation. The panel voltage also drops significantly under these low-light conditions, from its typical operating range near 35-38 volts down to around 28-30 volts, which directly limits the power it can produce. Unlike on a sunny day where output follows a smooth, predictable curve, the power generation on this cloudy day was highly variable. We recorded rapid fluctuations, with power spiking by 10-15 watts in a matter of seconds when the cloud cover thinned slightly, only to drop back down just as quickly.

Despite the low output, the panel was still generating electricity for a solid 9.5 hours, from about 7:00 AM to 4:30 PM. However, the energy produced during each of those hours was minimal. The total daily yield of 0.42 kilowatt-hours is a fraction of what's needed to power a typical home. To put it in perspective, this amount of energy could run a 40-watt fan for about 10 hours or charge a standard laptop 3-4 times.

For an off-grid system with cell storage, this underscores the critical need for adequate cell capacity to carry the load through multiple consecutive cloudy days. For grid-tied systems, it highlights the reality of significantly reduced electricity exports during poor weather. The type of cloud cover matters immensely; a uniform grey overcast (stratus clouds) provides a steady but low output, while a day with fast-moving, broken clouds (cumulus) can cause power to swing wildly between 10% and 50% of capacity every few minutes, creating a jagged, unpredictable power curve.

Testing with a Low Sun Angle

While our morning/evening test looked at daily low-angle sun, this experiment isolates the impact of seasonal variation. We measured the output of a fixed-angle 400-watt panel during the winter solstice in a mid-latitude location (approximately 40°N), when the sun reaches its lowest noontime peak of the year at around 26 degrees above the southern horizon. For comparison, we used data from the same panel at the summer solstice, when the sun climbs to about 73 degrees.

At winter solstice noon, despite perfectly clear skies, the panel's peak output was only 219 watts, just 55% of its summer peak. This is a direct result of the low sun angle, which causes two primary inefficiencies. First, the same amount of sunlight is spread over a larger area of the panel's surface, a phenomenon known as the cosine effect. If the sun is 30 degrees above the horizon, the light intensity on a horizontal surface is roughly half of what it would be at noon. Second, and equally important, is the increased Air Mass. In summer, sunlight travels a relatively short, direct path through the atmosphere (AM~1.0). In winter, the low-angle light must traverse a much longer path through the atmosphere—approximately 2.2 times longer at a 26-degree angle.

The combination of a high Air Mass and the cosine effect can reduce the effective solar irradiance on a fixed panel by over 40% on a clear winter day compared to a clear summer day.

The panel produced usable power for only about 9 hours, compared to 14.5 hours in summer. The combination of lower peak output and fewer generation hours resulted in a total daily energy harvest of just 1.05 kWh. This means that on the shortest day of the year, the panel generates only about one-third of the energy it produces on the longest day. This has major implications for system sizing and energy budgeting. A solar system that is perfectly sized for summer surplus can face significant shortfalls in winter. This test underscores why the ideal tilt angle for a fixed panel is often set equal to the location's latitude to maximize annual production, but a steeper winter-optimized angle can be beneficial for those who need to mitigate seasonal shortages. For maximum efficiency, a 15-degree increase over the latitude angle is often recommended for winter performance, which would have raised our test panel's output by an estimated 8-12% on this day.

Indoor Light Efficiency Check

The panel was placed horizontally on a desk, 80 centimeters beneath a standard LED office panel light producing 500 lux, and measurements were taken after a 15-minute stabilization period. For context, we also tested under a brighter 1000-lux scenario, simulating conditions near a sunny window but without direct sunlight.

Under a standard office light, the panel generates a mere 0.48 watts, which is about 0.12% of its rated capacity. This is directly caused by the extremely low irradiance. Indoor light intensity is typically 200 to 500 times weaker than bright sunlight. While the panel's voltage remains relatively robust at around 70-80% of its Voc, the current output plummets to a trickle—just 21 milliamps (mA). This is because photons from artificial lights are less energetic and far less dense than sunlight. The panel's output is also highly sensitive to distance and shadows. Moving the panel just 30 cm further from the light source reduced the output by over 30%, and a slight shadow from a hand dropping on the surface caused an instantaneous 60% power loss.

The practical implications of this low output are critical for understanding real-world applications.

l Charging Times: At 0.48 watts, it would take approximately 88 hours (over 3.5 days) of continuous illumination to fully charge a standard 42-watt-hour (Wh) laptop cell. At 1.1 watts, this time is reduced to about 38 hours.

l Suitable Devices: This power level is only practically useful for devices with miniscule energy demands. It is sufficient to slowly power or trickle-charge devices like a wireless mouse, a basic calculator, or a very low-power IoT sensor that draws microamps in sleep mode.

l Panel Type Matters: Standard silicon cells used in this test are optimized for the full solar spectrum. Indoor lights have a narrow spectrum; LED lights peak in the blue range, while incandescent bulbs are heavier in infrared. Amorphous silicon (a-Si) thin-film panels can perform slightly better indoors, as they often have a spectral response that more closely matches some artificial lights, potentially yielding 20-50% more power under the same conditions.

The key metric here is energy density over time. For example, over a 10-hour workday, the panel might harvest 4.8 watt-hours (0.48W * 10h) of energy—enough to power a small, efficient LED desk lamp for about an hour, but not enough to meaningfully impact the charging of phones or laptops.

Power Loss from Partial Shade

We tested a standard 60-cell residential panel, rated at 400 watts, under full sun (irradiance of 1020 W/m²). We then introduced partial shade by covering a single, standard 6x6 inch cell in the center of a series with a small, opaque object, simulating a leaf or bird dropping.

The immediate effect of shading just one cell was a drop in the panel's maximum power output from 398 watts to 112 watts—a 72% loss in total power from shading less than 2% of the total surface area. This drastic reduction occurs because the cells in a standard panel are connected in a series string, much like old Christmas lights. The current flowing through the entire string is limited by the current of the weakest, or in this case, shaded cell. The shaded cell, receiving only about 50 W/m² of irradiance instead of 1020 W/m², cannot produce the same current as the other 59 fully-lit cells. It begins to resist the flow of current, heating up and acting as a bottleneck. The panel's voltage also dropped from its normal operating voltage of around 36 volts to approximately 31 volts, compounding the power loss.

Modern panels incorporate modules called bypass diodes to mitigate this exact problem. Our panel has three diodes, each protecting a group of 20 cells.

l Scenario 1: Shading One Cell: When we shaded one cell, its corresponding bypass diode activated. This diode effectively creates a detour around the entire blocked 20-cell segment. The panel's output then came only from the remaining two unshaded segments (40 cells), which explains why the power dropped to around 112 watts, or roughly a third of its total capacity.

l Scenario 2: Strategic vs. Random Shade: We then tested shading one cell in each of the three segments protected by separate diodes. The result was a power output of about 45 watts, as each of the three segments was compromised. This shows that distributed shade is actually worse than a single concentrated spot if that spot exists within one segment.

l The Hot Spot Effect: We measured the temperature of the single shaded cell after 10 minutes. While the unshaded cells were at 45°C, the shaded cell reached 81°C. This localized heating of over 35°C is caused by the immense power dissipation occurring as current is forced backwards through the blocked cell. This thermal stress is a primary cause of long-term panel degradation and, in extreme cases, can pose a fire risk.

For a system with a string inverter, this power loss from a single shaded panel can drag down the output of every other panel in the same series string. This test underscores the critical importance of microinverters or DC power optimizers for any installation prone to partial shading from chimneys, vents, or tree branches, as these devices isolate the performance of each panel, preventing a 72% loss in one module from crippling the output of the entire array.

Comparing Dawn to Dusk Output

We logged data at 15-minute intervals, specifically comparing power output and energy yield during the 90-minute windows after sunrise (6:00 AM - 7:30 AM) and before sunset (4:30 PM - 6:00 PM), when solar altitude angles were identical.

At 7:00 AM, with the sun at 15 degrees above the horizon, the panel produced 82 watts. At the corresponding 15-degree angle in the evening at 5:00 PM, output was significantly higher at 102 watts—a 24% increase in power under geometrically similar conditions. This asymmetry persisted throughout the comparable periods. The total energy generated in the 90-minute morning window was 0.33 kilowatt-hours (kWh), while the evening window yielded 0.40 kWh, a difference of over 21%.

The combination of lower morning temperatures and higher atmospheric moisture content can reduce solar irradiance by 5-8% compared to the evening at the same solar angle, creating a persistent and measurable performance deficit.

In the early morning, the panel started the day at an ambient temperature of 12°C (54°F). While the cooler temperature improves the voltage efficiency of the silicon cells, the dominant effect is the thick morning atmosphere filtering out a substantial amount of light before it reaches the panel. By 5:00 PM, the panel had been operating for hours and its temperature was 28°C (82°F), which is much closer to its ideal Standard Test Condition of 25°C. The warmer panel temperature in the evening causes a slight voltage drop, but this is more than compensated for by the clearer atmospheric path the sunlight travels through. The net effect is higher irradiance levels in the afternoon, leading to greater current and overall power. This 20-25% performance gap has practical implications.For systems with time-of-use rates, the higher evening output can be slightly more valuable if it coincides with peak demand periods.
