Which is better mono or poly solar panels

Monocrystalline silicon has a conversion rate of approximately 22%, while polycrystalline is about 18%.

For the same area, monocrystalline is more efficient at generating electricity and has slightly higher costs, making it better for long-term returns in space-constrained scenarios.

Efficiency  and   Performance

Conversion Rate Comparison

Monocrystalline silicon cells are sliced from monocrystalline silicon rods with a purity of 99.999%. The conversion efficiency of mass-produced modules has now steadily entered the range of 21.5% to 23.2%.

In contrast, polycrystalline silicon has a higher electron recombination loss during the photoelectric conversion process due to the disordered arrangement of internal crystals, and its conversion efficiency is typically maintained between 15% and 17.5%.

Under a standard test environment of 1000 watts per square meter of light, a 2-square-meter monocrystalline module can generate 440 to 460 watts of power, while a polycrystalline module of the same size can only output 310 to 340 watts.

The power output per unit area of monocrystalline is more than 30% higher than that of polycrystalline.

From the perspective of cell structure, the current mainstream monocrystalline PERC technology can increase internal reflectivity by about 10%, while more advanced N-type TOPCon monocrystalline cells have reached mass-production efficiencies exceeding the 25% threshold.

Polycrystalline technology basically stopped large-scale technical iterations around 2019. The Fill Factor (FF) of its modules usually fluctuates between 72% and 75%, while the fill factor of monocrystalline modules generally reaches 78% to 81%.

In actual operation, this parameter gap of 5% to 9% directly leads to monocrystalline systems generating 50 to 80 more peak sunlight hours per year than polycrystalline systems under the same installed capacity.

High Temperature Resistance

The power temperature coefficient of monocrystalline modules is usually between -0.34%/°C and -0.39%/°C, while the coefficient for polycrystalline modules is around -0.41%/°C to -0.45%/°C.

When the rooftop temperature soars to 75 degrees Celsius at noon in summer, because the environment is 50 degrees higher than the standard test temperature, the power loss of monocrystalline panels is approximately between 17% and 19.5%.

Under the same high temperature of 75 degrees Celsius, the power loss of polycrystalline panels expands to a range of 20.5% to 22.5%.

This means that in hot regions where temperatures exceed 35 degrees Celsius, the actual effective power output of monocrystalline panels will be 3% to 5% higher than that of polycrystalline panels.

If the ventilation and heat dissipation conditions at the back of the modules are considered, since monocrystalline silicon wafers are thinner, their heat dissipation rate is about 8% faster than that of 180-micron thick polycrystalline silicon wafers.

During a 10-hour sunshine cycle, the internal operating temperature of monocrystalline panels is usually 2 to 3 degrees Celsius lower than that of polycrystalline panels.

This temperature difference not only improves instantaneous power generation but also reduces the DC input voltage fluctuation range of the inverter by about 15 volts.

Low Light Power Generation

In low radiation environments such as early morning, evening, or cloudy and rainy days, monocrystalline silicon has a wider spectral response range, and its relative efficiency retention rate under 200 watts per square meter of weak light remains above 95%.

Because polycrystalline silicon has more impurities at the grain boundaries, its ability to absorb long-wavelength light is weak, and its efficiency retention rate under weak light often falls between 85% and 90%.

If an area has more than 120 cloudy and rainy days per year, the amount of electricity generated by the monocrystalline system from scattered light will be 10% to 15% higher than that of the polycrystalline system.

Analyzing from the perspective of Light-Induced Degradation (LID), the power drop of monocrystalline modules within the first 24 to 48 hours after installation is usually controlled between 1.5% and 2%.

Due to the unstable content of boron-oxygen complexes, the first-year degradation rate of polycrystalline modules often reaches 2.5% to 3%.

Every morning after the sun rises, monocrystalline systems can usually reach the inverter's startup voltage threshold 15 to 20 minutes earlier than polycrystalline systems, and can shut down 10 to 15 minutes later in the evening.

Calculated cumulatively, the effective daily working time of a monocrystalline system is about 30 minutes longer than that of a polycrystalline system.

Area per Watt Ratio

Installing a 1 kW monocrystalline solar system usually requires only 4.5 to 5 square meters of net space.

To install a polycrystalline system of the same 1 kW capacity, an installation area of 6.5 to 7 square meters must be prepared.

On a 100-square-meter roof, 20 kW of installed capacity can be arranged with monocrystalline, while only 15 kW can be fitted with polycrystalline, a total capacity reduction of about 25%.

This difference in area utilization creates a chain of cost linkages. Because the number of panels is reduced by 20% to 30%, the length of supporting photovoltaic brackets, DC combiner box connectors, and cable consumables for monocrystalline systems are correspondingly reduced by more than 15%.

The common 182 mm or 210 mm large wafer design of monocrystalline modules allows a single module's power to reach 550 watts or even 670 watts.

Current specifications for polycrystalline modules mostly remain between 300 watts and 350 watts.

When installation workers handle and fix panels, the labor cost for monocrystalline solutions is reduced by about 0.1 RMB per watt compared to polycrystalline solutions.

Power Loss Rate

The average annual power degradation rate of monocrystalline panels is usually between 0.4% and 0.55%, ensuring that the output power after 25 years remains above 85% of the initial rated power.

The annual degradation rate of polycrystalline modules is generally around 0.7% to 0.8%. By the 25th year, their output power often only remains at 80% or even lower.

This 5% difference in end-of-life power generation capacity corresponds to a difference in annual electricity bill income between 400 and 600 RMB for a 10 kW system.

In the event of extreme weather such as hail or strong winds, the mechanical load-bearing capacity of monocrystalline silicon is usually above 5400 Pascals of pressure, and the probability of micro-cracks is about 12% lower than that of polycrystalline.

The grain boundary weaknesses inside polycrystalline modules are more likely to develop invisible micro-cracks when subjected to stress impact, leading to a local resistance increase of more than 50%, which in turn forms a hot spot effect.

These hot spots can cause local temperatures to instantly rise to over 100 degrees Celsius, shortening the overall lifespan of the module by 5 to 8 years compared to monocrystalline.

In actual operation and maintenance statistics, the failure report rate of monocrystalline modules after 15 years of operation is only 0.8%, while the report rate for polycrystalline modules is as high as 2.3%.

Long-term ROI

Return on Investment

The Internal Rate of Return (IRR) of monocrystalline photovoltaic systems in the current mainstream market can usually reach between 11% and 14%, and their investment payback period is approximately between 5.5 and 6.8 years.

Because the power generation capacity of polycrystalline systems declines faster in the later stages, their IRR usually hovers in the range of 8% to 9.5%, and the time to recover the initial investment needs to be extended to 7.5 or even 9 years.

If a $10,000 monocrystalline system breaks even in the 6th year, it will generate more than $28,000 in net profit over the remaining 19 years of the contract.

In a 25-year balance sheet, the Net Present Value (NPV) of a monocrystalline system is usually $3,500 to $5,000 higher than that of a polycrystalline system.

If tax credit policies are taken into account, because the total price of the monocrystalline system is slightly higher, the 30% federal tax credit amount obtained by investors in the first year will result in about $200 more in cash back compared to a polycrystalline system.

This early cash flow advantage can further shorten the repayment cycle by 4 to 6 months.

In the housing resale market, the valuation increase for properties with high-efficiency monocrystalline systems installed is typically around 4.1%, while the valuation increase for polycrystalline systems is only 2.8%. This 1.3% difference in house prices is an additional premium of $6,500 on a $500,000 home.

Second-hand Value

After 15 years of system operation, because the crystal structure stability of monocrystalline silicon modules is 25% higher than that of polycrystalline, their residual value in the second-hand equipment trading market can usually be maintained at about 20% of the original price.

Because the internal micro-crack rate of polycrystalline panels usually reaches over 15% after 15 years of operation, their second-hand recycling price is often only 5% to 8% of the original procurement cost.

In the system decommissioning stage, the scrap recycling income from monocrystalline panels can be about $300 to $450 more than that of polycrystalline panels.

Monocrystalline panels can still be sold for $0.03 per watt after 15 years of operation, while polycrystalline panels of the same age have a recycling value of almost only $0.008 in the market.

The transparency of the encapsulation glass for monocrystalline panels usually only drops by 2% after 20 years, while polycrystalline panels often experience a light transmittance loss of more than 5% due to encapsulation processes and material aging.

This difference in physical characteristics results in monocrystalline modules still contributing 4 to 5 hours of effective power generation daily in the last 5 years of their life.

By contrast, when the light intensity is lower than 300 watts per square meter, the output current of polycrystalline modules is often already unable to drive the inverter to work normally, resulting in a total lifecycle utilization rate that is 15,000 hours lower than that of monocrystalline.

Environmental Conditions

Heat Sensitivity

The power output of solar panels will experience a significant physical drop as the ambient temperature rises, and monocrystalline silicon modules exhibit stronger thermal stability in this indicator.

The power temperature coefficient of monocrystalline panels is usually controlled between -0.34%/°C and -0.38%/°C, while this coefficient for polycrystalline panels generally falls in the range of -0.40%/°C to -0.46%/°C.

When the temperature of a metal roof at noon in summer reaches 75 degrees Celsius, the module surface temperature is 50 degrees higher than the standard test environment of 25 degrees Celsius.

At this time, the power loss of a monocrystalline panel is approximately 17% to 19%, and a module that was originally 400 watts can still output 324 watts.

Under the same 75-degree Celsius environment, the power loss of polycrystalline panels will rapidly expand to 20% to 23%, and the output power may only be 308 watts or even lower.

This power output gap of around 5% will lead to a difference in total power generation of 80 to 120 kWh during a 4-month summer high-temperature period.

The internal single-crystal structure of monocrystalline silicon experiences about 15% less internal stress during thermal expansion and contraction than polycrystalline silicon.

This allows monocrystalline panels to typically have a power degradation rate of less than 2% after undergoing 200 thermal cycles from -40°C to 85°C, while the degradation rate of polycrystalline panels often exceeds 3.5%.

Cloudy Weather Performance

Under continuous cloudy and rainy weather, monocrystalline silicon has a stronger ability to capture faint light, and its internal electron mobility is about 20% higher than that of polycrystalline silicon.

Under weak light conditions of only 200 watts per square meter, monocrystalline panels can still maintain about 95% of their rated efficiency, while the efficiency of polycrystalline panels will drop to about 85%.

For an area with an average of 150 cloudy and rainy days per year, the amount of weak light electricity collected by the monocrystalline system is 150 to 250 kWh more than that of the polycrystalline system.

Wind and Snow Resistance

Monocrystalline modules are typically designed with 3.2 mm thick tempered glass combined with high-strength aluminum alloy frames.

Their ability to withstand positive pressure (simulating snow load) reaches 5400 Pascals, and their ability to withstand back pressure (simulating wind load) is 2400 Pascals.

Due to manufacturing processes and cost constraints, although polycrystalline modules list similar parameters, in an actual 25-year exposure environment, the probability of micro-cracks occurring in polycrystalline silicon wafers—due to the large number of internal grain boundary weaknesses—is about 18% higher than in monocrystalline when subjected to mechanical vibration caused by strong winds.

When hit by 25 mm diameter hailstones at a speed of 23 meters per second, the statistical data for tempered glass breakage in monocrystalline modules is around 0.05%, while the proportion of broken grid lines inside polycrystalline modules is 1.2 percentage points higher than in monocrystalline due to uneven stress on the silicon wafers.

When the thickness of snow on the roof reaches 50 cm, the static pressure per square meter is about 150 kg, and the frame deformation rate of monocrystalline panels usually remains within 0.5%.

Long-term high-load pressure will lead to the "snail trail" phenomenon on cells.

The incidence of snail trails in monocrystalline modules after 10 years of operation is only 0.3%, while in polycrystalline modules, this proportion often rises to between 1.5% and 2% due to poor material consistency.

Humid Environments

In high-humidity areas exceeding 85% relative humidity or in coastal salt-mist environments, solar panels face a serious risk of Potential Induced Degradation (PID).

Monocrystalline modules now widely use dual-glass encapsulation or improved POE encapsulation materials, which have a water vapor transmission rate of only 0.01 g/m²/day.

This is more than 10 times higher in water resistance performance than the EVA encapsulation materials used in traditional polycrystalline modules.

In dual-high tests of 85 degrees Celsius and 85% humidity, the power degradation of monocrystalline modules after 1000 hours of testing is usually controlled within 1.5%.

In contrast, polycrystalline modules in the same harsh environment often experience power degradation between 3% and 5% because charge accumulation at the edges of the silicon wafers is more severe.

This results in the performance stability period of monocrystalline systems being a full 6 years longer than that of polycrystalline systems in tropical rainforest climates or installations within 500 meters of the sea.

The busbars of monocrystalline modules usually use high-thickness tin-plated copper ribbons combined with more securely sealed junction boxes (waterproof rating IP68), keeping the increase in contact resistance after 15 years usually below 0.05 ohms.

After 15 years of operation, due to water vapor infiltration caused by aging encapsulation layers, the junction box failure rate for polycrystalline modules is about 2.5% higher than for monocrystalline, which leads to an additional annual maintenance cost of $50 to $80 for the system.

Dust Accumulation

Anti-reflective coatings and self-cleaning glass technology used on the surface of monocrystalline modules can reduce dust adhesion by 20% to 30%.

In arid regions with sparse rainfall, under the same condition of not being cleaned for 30 days, monocrystalline panels lose about 5% to 7% of power due to more uniform surface charge distribution, while polycrystalline panels lose 8% to 12% because their complex surface textures make it easier to harbor dirt.

Experimental data shows that when the surface is covered with 10 grams of dust per square meter, the short-circuit current (Isc) of monocrystalline panels drops by 6.5%, while the drop for polycrystalline panels reaches about 9.2%.

During manual cleaning, the flat surface of monocrystalline panels improves cleaning efficiency by 15%, and the water consumption per hundred panels is saved by about 50 liters compared to polycrystalline panels.

If a cleaning frequency of four times per year over 25 years is considered, the total expenditure on maintenance water and labor for monocrystalline systems is approximately 12% less than the budget for polycrystalline systems.
