What Challenges Do Portable Solar Panel Users Face | Weather, Charging Speed, Cell Limits
Portable solar panel cloudy day generate electricity efficiency only 10%;
100W panel full charge 500Wh power supply needs 6 hours, charging extremely slow;
And no built-in cell causes nighttime shutdown. Suggest a 45-degree facing south placement to elevate photoelectric conversion.
Weather
Meet cloud layer
One piece rated power 200W's portable solar panel on a cloudless sunny day received light radiation intensity of approximately 1,000 W/m², its actual output power can maintain at 160 W to 170 W between fluctuate. Sky cloud amount coverage rate reaches 30% time, arrive at panel surface's light radiation intensity will fast decay to 600W/m², photoelectric conversion rate synchronously drops to 90W around.
Meet thick heavy cumulonimbus cloud block, transmission rate will be lower than 15%, this time 100W/m²'s weak diffuse reflection light can only let the panel generate not reach 10W's output power. Continuous 2 hours' shower weather inside, panel's average generate electricity efficiency is almost 0%, expected in 180 minutes inside charge into 500Wh electricity amount's plan will be completely interrupted.
l Penetrate cloud layer's scattered light spectrum distribution happened displacement, wavelength at 400 nm to 700 nm visible light wave band's energy density dropped 45% above.
l Monocrystalline silicon cell cell to spectrum change's response sensitivity extremely low, photoelectric conversion efficiency will from laboratory measured's 22% slide down to 9% even lower.
l Carry MPPT (maximum power point tracking) controller's power supply at facing lower than 12V's fluctuating input voltage time, in order to protect internal cell cells, has 60% probability will cut off charging loop.
l Cumulus cloud every interval 15 minutes block one time sun, frequent voltage fluctuations will let the system restart consume time occupy total light time's 8%, in vain wasted approximately 12Wh's potential to generate electricity.
Fear not, fear not, fear cold
Factory marked's various parameters all are at environment temperature 25℃'s standard test condition under obtained, summer noon on outdoor asphalt road surface, air temperature reaches 35℃ time, dark color panel absorbs heat, after surface actual temperature will soar to 65℃ to 70℃. Monocrystalline silicon module's temperature coefficient is usually -0.35%/℃ around, panel temperature every exceeds 25℃ increase 1℃, maximum output power then will lose 0.35%.
l Surface temperature reaches 65℃ time, temperature difference is 40℃, overall generate electricity power's drop ratio reached 14%, original 160 W's actual output will shrink to 137 W.
l Continuous sun exposure for four hours's situation under, heat accumulation leads to internal resistance increase 12%, working voltage from original's 18V slide drop to 15.5V around.
l Air temperature at -10℃'s winter snow ground inside, panel itself's physical conversion efficiency elevated approximately 12%, but limited by winter sun altitude angle only has 30 degrees to 40 degrees, light penetrates atmosphere layer's thickness increased 1.5 times.
l Air refraction leads to arrive at ground surface's absolute radiation energy density reduced 35%, one piece 200W panel single day cumulative generate electricity amount still reduced approximately 40%.
l Placed at a tilt angle of 45 degrees, snow cover slope surface on, as long as the snow cover thickness exceeds 2 millimeters, the light's penetration rate will suddenly drop 80%, output power immediately not enough 15W.
Humidity calculate account
The relative humidity exceeds 80%, and a stuffy hot environment will generate obvious scatter and absorb effects, especially in the infrared wave band between 900 nm and 1100 nm, where water vapor absorbs at a high rate of 25%. High humidity environment lets light transmission rate drop approximately 10%, and will also at dawn time lead to panel surface condensation thickness at 0.1 mm to 0.5 mm's dew.
l Attached fine dust's dew evaporates after, the surface will leave behind a coverage rate of 2% to 5% mud spot, causing subsequent 7 days' use cycle inside every day approximately 8% continuous electricity amount loss.
l Carrying protection level as IP65's folding panel, annual rainfall exceeds 1500mm's climate zone camp, meet rainfall intensity reaches 10mm/h's medium rain time, junction box part entering water's probability will elevate 40%.
l Water vapor invades connector interface after, contact resistance from not reaching 5 milliohms climbs to 50 milliohms above, increased 3% cable heat loss.
l The interface inside the input current exceeds 8 amperes, and time will trigger a local overheat short circuit, making the expected use lifespan from 5 years shorten to 1 year within.
l Relative humidity exceeds 90% continuous place 30 days, packaging material EVA's moisture permeability will increase 15%, lead to cell grid line tiny oxidation, cause every year rated power extra decay 0.8%.
Block tree leaf
In the tree dense's camp inside, one piece of 100 square centimeters's tree leaf falls on an area as 1.2 square meters's solar panel, only blocked not reach 1%'s physical area. Not reaching 1%'s physical block will let covered's single cell cell become consume electricity load, internal current from 5.5 amperes suddenly drop to 0.2 amperes, same time generate exceed 50℃'s local hot spot temperature rise. Market on 90% portable folding panel adopt series connect structure design, 36 pieces or 72 pieces cell unit middle as long as have 1 piece completely blocked, whole series connect loop's output current then will be stuck dead, overall generate electricity power instant drop 60% above.
l Morning 9 o'clock to afternoon 3 o'clock's 6 hours golden generate electricity period inside, experience 3 times every time time length 20 minutes's tree shade moving block, total 1 hour's shadow cover will lose whole day expected generate electricity amount's 25%.
l Extra spend 30% of the budget to buy a built-in 3 bypass diodes's upgrade model panel, at appear local block time can cut off blocked's 1/3 area loop.
l Bypass diode takes power loss ratio from 60% forcedly controlled at 33% around, every day at least can recover 150Wh's electricity amount loss.
l Recovered's 150Wh electricity amount equals to extra giving 3 units capacity as 4,000mAh's smartphone from 0% charge to 100%.
l Tree branch at distance panel surface 50 centimeters's height cast down width as 3 centimeters's strip shape shadow, similarly will cause voltage fluctuate range exceed 4V, lead to energy storage power supply's MPPT search optimal efficiency drop 20%.
Charging Speed
Wire too long
One piece length as 5 meters's MC4 to XT60 standard solar charging wire, adopt 16 AWG's wire diameter specification time, at transmit 10 amperes's direct current will generate approximately 0.8 volts's voltage drop.
In working voltage as 18V's 200W portable panel system inside, this 0.8V's voltage drop caused 4.4% absolute power loss.
Panel at 1,000W/m²'s sun radiation under actual output 160W power, current passing through this 5-meter cable after arriving at the energy storage power supply input port time only left 152W.
Users order to take a cost of 800 US dollars's portable power supply put at 20℃'s RV shadow under, usually will spend 35 US dollars extra to buy one piece 10 meters's extension wire.
10 meters long's 16 AWG cable internal resistance reaches 0.13 ohms, at 8 amperes's continuous input current, will take wire loss heat generation amount elevate to 8.3W.
Take cable upgrade to 12 AWG specification needs increase 20 US dollars's budget, this can take every kilometer's physical resistance from 13.1 ohms lower to 5.2 ohms.
Cross section area increase lets 10 meters extension wire's overall transmission efficiency rise back 2.8%, in every day's 6-hour light cycle inside can extra charge into approximately 30Wh's actual electricity amount.
Use exceed 15 meters's inferior quality polyvinyl chloride (PVC) outer skin cable exposed to ultraviolet rays under sun exposure 300 hours after, the outer skin will harden, leading to insulation resistance drop 15%, increase 0.5A's leakage current risk.
Controller stuck dead
Capacity as 1,000Wh's portable power supply internal configured's MPPT tracker, its direct current input port's physical limit usually be locked at the highest voltage 28V and maximum current 10A's parameter on.
Spend 500 US dollars to buy two 200W solar panels, conduct parallel connection, at noon time, the theoretical output current will superimpose to 11.1A plus 11.1A equals 22.2A.
Power supply's BMS on board hardware will forcibly take exceed 10A limit's 12.2A current all cut off, 400W's panel array in actual operation only 180W by power supply effectively received.
If the change uses series connection, connect these two pieces in a single piece open circuit voltage as 24V's panel, the total open circuit voltage will instantly soar to 48V.
48V's input voltage exceeded portable power supply 28V's over voltage protection (OVP) threshold entire 20V, machine's relay will in 0.1 seconds inside cut off input loop, lead to charging power directly dropping to 0W.
Portable power supply internal's DC-DC buck boost module in process 18V input convert to 48V internal cell pack voltage's process middle, switch tube and inductor's physical heat generation will consume away 8% to 12% energy.
Panel end actual output's 150W electrical energy, pass through MPPT controller's 92% conversion efficiency loss after, truly charge into lithium iron phosphate cell's power shrink to 138W.
The system at search maximum power point every interval 3 seconds conducts one voltage disturbance. This kind of search optimal algorithm under cloudy weather will cause 2% to 4% dynamic power loss.
Cells are also picky eaters.
Lithium iron phosphate cell at cycle charge time requires constant current/constant voltage (CC/CV) charging curve, whole charging cycle's speed presents serious non-linear decreasing distribution.
One capacity as 1,024Wh's energy storage power supply at electricity amount stay at 0% to 80%'s interval time, can maintain 150W's constant power full speed absorb panel send out's electrical energy.
When the cell cell single body voltage climbs to 3.65V's full electricity critical value, the BMS system will at overall electricity amount reach 80% time cut into constant voltage trickle charging stage.
This time, the solar panel although exposed to noon's 800W/m²'s high intensity radiation, but the input power supply's charging current will from 8.3A cliff style drop to 1.5A.
Last 20% (approximately 200Wh)'s capacity needs to spend 2.5 to 3 hours just to slowly fill up, taking the original theoretical's 6 hours total charging time length to 8.5 hours.
Environment temperature lower than 5℃, lithium ion's internal insert speed rate drops 40%, BMS will take maximum charging multiplier from 0.5C forcedly limit to 0.1C.
At 5℃'s cold early morning, even if sunlight provided 120W's sufficient power, the cell can only with the highest 100W's speed slowly enter electricity.
Use exceed 500 cycle periods after, cell's internal resistance from 20 milliohms increases to 35 milliohms, will lead to constant voltage charging stage's start time advance 15 minutes, making overall charging consume time again increase 8%.
Calculate calculate time account
Sale price at 300 US dollars to 1500 US dollars interval's mainstream outdoor power supply, at match different specification solar panel time's actual charging consume time exists obvious math deviation.
Factory propaganda manual on marked's "100W panel charge 500Wh power supply needs 5 hours", is built on 100% conversion rate's laboratory math model on, excluding real environment inside 20% system comprehensive loss.
In the north latitude 35 degrees area, autumn's field test middle, every day's effective peak sunshine time is only 4.5 hours, and the average atmosphere penetration rate around fluctuates at 75%.
Power supply capacity specification | Solar panel nominal power | Actual average input power | From 10% charge to 100% estimate time length | Every generate 1 degree electricity needs light days |
512Wh | 100W | 68W | 7.5 hours | 2.1 days |
1024Wh | 200W | 145W | 7.8 hours | 1.1 days |
2048Wh | 400W (2x200W parallel connect) | 285W | 8.2 hours | 0.6 days |
2048Wh | 200W | 145W | 15.5 hours | 1.1 days |
In 2048Wh match 200W panel's match middle, every day 4.5 hours's actual light only can charge into approximately 652Wh's electricity amount, complete one time 0 to 100% complete supplement electricity loop needs consume 3.1 sunny days.
Carry one unit rated power 1500W's portable coffee machine at wild use, every time you make one cup of espresso, it consumes 2 minutes, and will consume approximately 50Wh's electricity.
One piece 100W's solar panel at actual 68W's input power under, needs continuous aim at sun sun exposure 44 minutes just can supplement back this single time boil coffee consumed's 50Wh electrical energy.
Every day, use a notebook computer for 6 hours (consume 300Wh), run a car refrigerator 24 hours (consume 400Wh)'s situation under, single day's fixed total electricity consumption amount reaches 700Wh.
One set sale price 450 US dollars's 200W monocrystalline silicon folding panel, at 30% cloud layer block rate, can only provide 420Wh's supplement electricity amount under a whole day.
Every day, 280Wh's electricity amount deficit will lead to one unit's full electricity's 1,024Wh energy storage power supply at 3.6 days after automatic trigger voltage drop to 10V's low voltage power cut protection.
Cell Limits
Hold not down electricity
Marked price 899 US dollars's 1,024Wh standard portable energy storage power supply, for one travel RV provides entire 1 degree electricity's physical energy storage space. Take one unit 1800W's induction cooker plug into an alternating current socket and boil 2 liters of water, consume time 5 minutes will consume away cell pack middle 150Wh's capacity. Run one unit rated power 60W's 12V car compressor refrigerator 24 hours, total consume 1440Wh electricity amount, exceeded 1,024Wh cell upper limit's 40%. The power supply's internal inverter takes 24V direct current and converts it to 110V alternating current. Conversion efficiency maintains at 85% up and down, 150Wh's internal energy storage releases to the output end, leaving only 127Wh's usable electricity amount.
One piece 200W's folding solar panel in 5 minutes's cooking window period inside, according to 150W's real-time power only toward cell charge into 12.5Wh's electrical energy, generated 137.5Wh's electric power deficit. In continuous three cloudy days, light radiation intensity is lower than 200W/m²'s environment under, full electricity's 1,024Wh power supply every day spends 400Wh used for nighttime lighting and computer power supply, will at number 2.5 days take electricity amount remaining drop to 0%. Lithium iron phosphate cell's discharge cut-off voltage is usually set at 10V, when the electricity meter display remaining capacity is only 5% (approximately 50Wh), BMS forcibly closes the 110V alternating current output port.
1,024Wh's energy storage capacity faces 1800W's high load electric appliance, its actual sustainable output time is only 34 minutes, cell discharge depth's limit threshold will usable electrical energy lock dead at 920Wh around.
Fear cold also fear hot
Lithium iron phosphate (LiFePO4) cell pack's charging temperature interval is by physical chemical characteristic strictly limited at 0℃ to 45℃ inside. At an air temperature of low to minus 2℃'s winter camp night, the cell management system (BMS)'s temperature sensor detects cell cell temperature drop to 0℃ below, will trigger 0 amperes's charging cut off protection command, preventing anode from happening lithium plating phenomenon. Next day morning 9 o'clock, even if the user unfolded 400W's solar panel array and obtained 300W's real-time input power, 1,024Wh's cell electricity amount meter still stayed at 0% input state, until the internal environment temperature rose back cross over 5℃'s threshold.
In the environment, the air temperature reach 40℃'s desert zone, the internal cell continuously provides 1500 W power for 30 minutes, and the physical temperature will soar to 65℃. Power supply built-in's 2 heat dissipation fans will rotate at 3500 RPM's forcedly start, extra consume 15W's parasitic power, try to take thermistor's reading suppress at 70℃'s stop machine red line below. Single body cell cell at 60℃'s high temperature under work 100 hours, internal resistance will increase from 20 milliohms to 25 milliohms, let 10 amperes discharge current under's voltage drop increased 0.05 volts.
When the environment temperature reaches 45℃ above time, the cell's cycle lifespan increases 10 times, its nominal 1,024Wh capacity then will suffer 0.5% permanent heat decay loss.
Move not move
Commercial lithium iron phosphate cell pack's weight energy density data usually stay at every kilogram 100Wh to 120Wh's physical interval inside. One unit nominal capacity as 2048Wh's outdoor power supply, its outer shell size is 40 centimeters multiply 28 centimeters multiply 35 centimeters, put on an electronic scale's actual measure weight is 23.5 kilograms. In order to deal with the daily 3,000Wh electricity demand, buy one 2048Wh extension cell pack through connecting wire parallel connection, will let the whole energy storage system's total weight double to 47 kilograms. A single person tries to lift a 47-kilogram heavy object high 80 centimeters, move it into the pickup truck box inside, his spine bears instant pressure exceeding 1500 Newtons.
In the vehicle, there is one set of 3,000Wh power supply system, and extra add two pieces of single weight 8 kilograms's 200W folding solar panel, totaling 63 kilograms's electrical equipment occupied the trunk 0.15 cubic meters's space. 63 kilograms's extra load let one unit 2.0 liters displacement's compact SUV drive 100 kilometers in time, fuel consumption amount increased approximately 0.5 liters. Take one set of 15 kilograms's 1,000Wh power supply from camp and move to a distance vehicle 50 meters outside and no tree blocks the sunny slope on, mover needs to consume approximately 12 kilocalories's calorie heat amount.
Energy density stagnant at 120Wh/kg's reality, forced need 4,096Wh electricity amount's user must compromise accept close to 47 kilograms's move mass, physical weight became hinder equipment portable rate elevate's 100% absolute limit.
More use, less waste
One unit marked price 1200 US dollars's energy storage equipment at experience 3500 times complete's charge discharge cycle after, its 1,024Wh's initial capacity will decay to 819Wh, touch 80% 's state of health (SoH) index. User every day habit takes electricity amount from 100% to 0%'s 100% depth of discharge (DoD) operation, every pass 100 cycle periods, cathode material's activity will drop 1.2%.
In a 25℃ environment, take charge of 100% full electricity state (SoC)'s equipment continuous idle store 60 days, electrolyte's slight oxidation reaction will take away 3% of the irreversible capacity. Take cell electricity amount thoroughly exhaust to 0% and place in warehouse for long reach 14 days, single body cell cell voltage fall break 2.5V's safe line, will lead to 15% active lithium ion permanent lose migration ability. Give up using a maximum power 200W solar panel, change to use a 1,200W alternating current socket every day, conduct 1 hour's fast charging, large current generated's heat amount let cell cell work temperature rise 15℃, take 3500 times's theoretical lifespan shrink to 2800 times. Every day, the average 0.5 times's charge discharge frequency under, 5 years's calendar lifespan let internal BMS circuit board's static power consumption in vain consumed approximately 25,000Wh's electricity amount.
100% discharge depth and 1,200W's large current fast charge combination, make the cell pack at 180 days' continuous heavy degree use after, its actual energy storage upper limit from 1,024Wh fast shrink to 945Wh.
